The impulse generator system EMC 2015 has been designed for dielectric testing of electric components, over-voltage protectors and electronic circuits acc. IEC, VDE etc. The basic version generates impulse currents with waveform 8/20 µs and a peak value of up to 25 kA. In addition, various other plug-ins are also available.

The Power Fail Simulator PFS-CE-16 is a compact EMC test unit designed for testing electromagnetic immunity against interruption and variation of the power supply voltage acc. to IEC 61000-4-11. Demonstrating such immunity is generally a requirement of the European EMC directive, a necessary step leading to the final attachment of the CE mark.

High-voltage pulse generator producing Ring Wave 0.5 µs / 100 kHz acc. to IEEE 587. The output peak voltage can be preset continuously from 0.2 - 7 kV. Rise time 0.5µs to the first peak, ringing frequency 100 kHz. A built-in voltage divider allows the monitoring of the output voltage waveform. The generator comprises an electronically regulated high-voltage power supply, an energy storage capacitor, a high-voltage/high-current switch, a pulse forming network and control- and monitoring unit. Moreover, the generator includes a Coupling-/Decoupling Network (CDN) for single-phase power supply lines.

The high current pulse generators PG 6-400 / PG 6-200 are designed for surge testing of electrical components, over-voltage protectors and electronic circuits acc. to IEC, VDE etc. They generate standard impulse currents with waveform 8/20 µs. Short circuit output current amplitude is selectable from 0.2 up to 10 kA by adjustment of the charging voltage of the internal energy storage capacitor.

Discontinued - See EMC 2015

The high-current pulse generator PG 6-2402 is designed for surge current testing of electrical components, over-voltage protectors and electronic circuits acc. to IEC, VDE etc. It generates standard impulse currents with waveform 8/20?s. Pulse current output amplitude can be set to 2 - 50 kA.

The Electrical Fast Transient Generator EFTG-CE5 is a compact EMC test unit for testing electromagnetic immunity against electrical fast transients. The generator provides burst-pulses, which are adjustable in frequency, amplitude, duration and repetition rate. It is suitable to test the susceptibility levels of electrical systems and installations full compliant to IEC 61000-4-4.

The CWG-CE5 is a compact EMC test unit designed for testing electromagnetic immunity against pulsed and conducted interference. Demonstrating such immunity is generally a requirement for compliance with the European EMC directive, a necessary step leading to the CE mark.

The Combination Wave Generator CWG-CE7 is a combined impulse-current-/impulse-voltage generator which, for high-impedance loads, RL > 100?, delivers a standard impulse voltage with waveform 1.2/50?s and, for short-circuited output, a standard impulse current with waveform 8/20?s.

The Burst Calibration Kit has been designed to measure the pulse output voltage and the pulse output current of burst generators, e.g. the EFTG-CE5 or the burst generator sub-unit of the Multi-CE5. It essentially consists of a load resistor, a pulse voltage divider, and a double-shielded coaxial cable. ? Burst Calibration Kit ? Input voltage: 5 kV ? Ratio, 200/400:1 ? Bandwidth: 400 MHz

The external impedance IMP8 is the impedance, required for the pulse specifications according to standard IEC 61000-4-5 Ed.3, for measuring the pulse output voltage of surge generators.
