IEC/EN 50561-1

OTHER PRODUCTS IN THE SAME STANDARD:
ISN 50561-1, ISN for PLC measurement, acc. EN 50561-1

  • Impedance stabilization network (ISN)
  • For measurements of asymmetrical disturbance voltage of power line communication equipment
  • Acc. standard EN 50561-1:2012, Annex B, Figure B.1.

CS-50, 2 way splitter, 50 Ohms acc. EN 50561-1

  • A resistive, unsymmetrical two-way splitter
  • The impedance of 50 Ω
  • Acc. to EN 50561-1:2012 which is explained in chapter 9.2.
  • Figure 4 shows the measurement setup with the available components

SPLIT 100, 2 way splitter, 100 Ohms acc. EN 50561-1

  • A resistive, unsymmetrical two-way splitter
  • The impedance of 100 Ω
  • Acc. to EN 50561-1:2012 which is explained in chapter 9.2.
  • Figure 4 shows the measurement setup with the available components

SYMAT 40, Symmetrical Step Attenuator, 100 Ohms acc. EN 50561-1

  • Symmetrical 100 Ω step attenuator
  • Switchable between 0 dB, 10 dB, 20 dB, 30 dB, 40 dB and 50 dB
  • For measurement of PLC or PLT to discover dynamic performance
  • Acc. EN 50561-1:2012 chapter 9.2. Figure 4 shows the setup

SY 9223-50561-1, Symmetrical Transformer, 50 to 100 Ohms acc. EN 50561-1

  • Symmetrical transformer
  • Transforms an unsymmetrical 50 Ω signal into a symmetrical signal with an impedance of 100 Ω
  • Attenuates the power by 8 dB
  • Acc. to EN 50561-1:2012, chapter 9.2. Figure 4 shows the setup, figure 5 shows the principle diagram

CU 50561-1, Coupling Unit , acc. EN 50561-1

  • The coupling unit for measurements at powerline transmission devices.
  • Acc. standard EN-50561-1
  • Combined with two-line impedance stabilization networks (LISN)
