DO-160 Section 19

OTHER PRODUCTS IN THE SAME STANDARD:

The compact magnetic field generator and analyzer MGA 1033 allows susceptibility tests against magnetic fields from DC to 250 kHz according to the standard EN 55103-2 and their measurement according to EN 55103-1. In addition, EMC tests are possible according to various standards such as automotive, avionic and MIL-STD.; Generation of magnetic fields from DC to 250 kHz; Field strength up to 1000 A/m; EN 55103-1/2, MIL-STD 461, Automotive etc.; Accessories: Loop sensors, Helmholtz coils etc.;

  • Measurement of interference voltage in vehicles, aircraft, and ships
  • 10 kHz - 400 MHz
  • 1500VDC / 650VAC up to 400Hz
  • Max current 200A, (280A limited time)
  • Impedance of each path: 5 µH || 50 Ω ±20 %

  • Measurement of interference voltage in vehicles, aircraft, and ships
  • (1)10 kHz - 400 MHz
  • 600VDC / 530VAC up to 400 Hz, 270VAC up to 890 Hz
  • Max current 70A, (100A limited time)
  • Impedance of each path: 5 µH || 50 Ω ±20 %

  • DO 160 Section 19 Compliance: Generates chattering relay spike trains meeting RTCA DO 160 §19.3.5 and Boeing D6-16050-4 §7.5.2 requirements.
  • Adjustable High Voltage Pulses: Up to 600 V burst amplitude, 0.2–10 µs spike width, 50–1000 µs burst duration.
  • Intuitive Touchscreen Interface: 7″ display for real time control of polarity, burst length, and duty cycle.
  • Dual Monitor Outputs: Two 100:1 Banana ports (≥100 MHz bandwidth) for precise oscilloscope verification.
  • Robust Safety Design: Shrouded banana outputs, reinforced HV wiring, earth ground lug, and IP3X enclosure.
  • Compact & Portable: 235 × 180 × 140 mm, 2.3 kg—ideal for laboratory or on aircraft test environments



  • Low inductive precision high power shunt
  • 1 x 0.25 Ohm / 800 W
  • 1 x 1 Ohm / 800 W
  • 2 x 0.5 Ohm / 400 W
  • Use for many applications including meeting MIL-STD-461 requirements
