Products
Injection Clamp Kits (ICK) EM and BCI Clamps
Absolute EMC offers an assortment of injection test kits for the use of conducted immunity. The kits can be used with many available conducted immunity systems, including the Schlöder CDG 7000, to make selection and setup easy. All calibration fixtures, injection clamps, attenuators, and termination resistors necessary for meeting the requirements of conducted immunity systems. All all-in-one systems are covered.
MDS 21 C, 30 - 1000 MHz, EMI Absorbing Clamp
- EMI Absorbing Clamp
- 30 - 1000 MHz
- acc. CISPR 16 for interference power with silicon-coated rolls
- Also for shielding measurements on coax. cables
EMCL 6146, 10 - 1000 MHz, EM Coupling Clamp and CAL EMCL Cal Fixture
- Common-Mode Absorbing Clamp
- Usable frequency range: 10kHz - 1000MHz
- Meets EN / IEC 61000-4-6
- Cable bundles maximum diameter of 25 mm
- Optional Cal Fixture: CAL EMCL
FTC 101 C Decoupling Clamp
Decoupling Clamp
Improve decoupling between the injection clamp and auxiliary equipment.
The FTC 101 C is a ferrite decoupling clamp for conducted immunity setups using the EMCL 6146 RF-injection clamp. It increases isolation toward auxiliary equipment (AE) in IEC/EN 61000-4-6 testing while accommodating cables up to 25 mm in diameter.
CMAD 1614, 10 - 1000 MHz, Common Mode Absorption Device
- Common-Mode Absorbing Clamp
- (10) 30 - 200 (1000)MHz
- Suppress unwanted common mode currents
- Cable bundles maximum diameter of 26 mm
- acc. CISPR 16-1-4
CAL CMAD 1614, Calibration fixture for CMAD 1614
- Calibration fixture for Common-Mode Absorbing Clamp
- (10) 30 - 200 (1000)MHz
CVP 9222 C, 9 kHz - 100 MHz, High Impedance Capacitive Voltage Probe
- Calibration fixture for Common-Mode Absorbing Clamp
- (10) 30 - 200 (1000)MHz
CDG EMCL- NW 10 / MN-1 EM Clamp Matching Network
EMCL- NW 10 / MN-1 Matching Network • For use with the EMCL-20 in the frequency range 10 kHz – 150 kHz • For use with the CDN BCI-P1 in the frequency range 10 kHz – 150 kHz
CDG CDN EMCL-20 / CDG CDN EMCL-35 EM Clamp
EM Clamp for immunity tests IEC / EN 61000-4-6 Ed. 4.0 • EM Clamp for immunity testing of cables with up to 20 (35) mm diameter • High coupling factor: less than 15 watts amplifier output power is required to obtain a test level of 10 V • Calibration unit and calibration data are supplied with each unit.
CDG CDN ABCL-20 Decoupling Clamp
CDN ABCL-20 Decoupling Clamp for immunity according to IEC / EN 61000-4-6 Ed. 4.0 100 kHz – 1000 MHz Features: For additional decoupling at immunity testing according to IEC / EN 61000-4-6 Suitable for cables up to 20mm diameter
SW 9600 B2, 1 kHz–420 MHz, Bulk Current Injection Clamp
Bulk Current Injection Clamp
Inject disturbance currents into cables and cable bundles for conducted immunity testing.
The Schwarzbeck SW 9600 B2 covers 1 kHz–420 MHz and supports up to 30 W CW RF input. Its split-core design accepts cables up to 31 mm in diameter, connects through a 50-ohm N-female interface, and includes individual transfer-impedance calibration data.
SW 9602, 10 kHz - 200 MHz Current Transformer
- Current Transformer
- Shielded
- 0.01 - 200 MHz
- Transfer Impedance: 1 Ohm for wires up to 6.5 mm
