Products
PG-CS115 - CS115 Test Generator, 1kV into 50 Ohms
Benefits of the PG-CS115 Pulse Generator
- MIL-STD 461 Compliant: Meets stringent military standards for reliable testing.
- Flexible Configurations: Available as standalone (PG-CS115) or modular (M-CS115) units.
- Comprehensive Accessories: Optional injection probe, attenuator, oscilloscope, and control software.
- High Precision: Delivers accurate rectangular pulses with rapid rise/fall times (≤ 2 ns).
- Versatile Testing: Supports single and repetitive pulse rates from 1 to 50 Hz.
- Compact Design: Lightweight and portable, ideal for various testing environments.
- Reliable Performance: Durable construction ensures long-term use in demanding settings.
Enhance your EMC testing with the CS115 Pulse Generator—precision, compliance, and versatility combined.
CABAI20050, 200W, 50 A, 2:1, Audio Isolation Transformer
Audio Transformer 200W, 50A
- 160x155x200mm
- 2:1 ratio
- 200 W Maximum30Hz - 250 kHz
- 100 W Maximum at15 Hz - 30 Hz
- Insulation Resistance Test - 2kV
POG-CS116 - Test Generator, Dampened Wave
Highlights of the CS116 Damped Sinusoid Generator
- MIL-STD 461 CS116 Compliant: Meets stringent military testing standards.
- Flexible Frequency Options: Choose from 6, 9, or 17 test frequencies.
- Comprehensive Accessories: Includes injection probe, attenuator, oscilloscope, and control software.
- Efficient Operation: Single signal output reduces test time and supports automation.
- User-Friendly Control: Easily controlled via RS232 and USB interfaces.
- Robust Design: Durable construction with wide power compatibility (90–264 Vac).
- Upgradable: Add CS115, CS106, CS114
Optimize your naval and industrial testing with the CS116 Damped Sinusoid Generator—precision and efficiency combined.
PG1275F - MIL-STD-1275F Surge/Spike Test Generator
Benefits of the PG1275F Pulse Generator
- MIL-STD-1275F Compliant: Dedicated design for conducted susceptibility testing on 28 VDC circuits.
- Spike & Surge Testing: Handles spikes up to 250 V / 250 mJ and surges up to 100 V / 1210 J.
- High Current Capability: 16 A continuous or up to 400 A with the optional DM400 decoupling diode module.
- Adjustable Waveforms: Configurable rise times, pulse durations, and voltages for precise test conditions.
- User-Friendly Control: Remote interface via RS232 or USB, with optional control software for automated testing.
Enhance your EMC testing with the 1275F Pulse Generator—precision, compliance, and versatility combined.
POG-CS116-CS115 Test Generator, Dampened Wave and Switch Transients
Highlights of the CS116 Damped Sinusoid Generator
- MIL-STD 461 CS115+CS116 Compliant: Meets stringent military testing standards.
- Flexible Frequency Options: Choose from 6, 9, or 17 test frequencies.
- Comprehensive Accessories: Includes injection probe, attenuator, oscilloscope, and control software.
- Efficient Operation: Single signal output reduces test time and supports automation.
- User-Friendly Control: Easily controlled via RS232 and USB interfaces.
- Robust Design: Durable construction with wide power compatibility (90–264 Vac).
Optimize your naval and industrial testing with the CS116 & CS115 Damped Sinusoid & Switch Transient Generator—precision and efficiency combined.
ONYX VISION 8, 8kV ESD Simulator w/Camera
An 8 kV ESD simulator for contact and air discharge testing, with a built-in camera and a 3.5-inch color touchscreen. See the discharge point live and save images before and after an impulse to support test documentation.
The portable ESD gun includes a 150 pF / 330 ohm RC network, two rechargeable battery packs and USB-C charging. Increase the voltage capability later with a purchased unlock code for a higher-voltage ONYX VISION configuration.
ONYX VISION 16, 16kV ESD Simulator w/Camera
An 16 kV ESD simulator for contact and air discharge immunity testing. Its integrated 1.5-megapixel camera displays the test point on a 3.5-inch color touchscreen and saves photographs before and after an impulse.
Includes a 150 pF / 330 ohm RC network, two rechargeable batteries and USB-C charging. Upgrade to 30 kV later with a purchased unlock code.
ONYX VISION 30, 30kV ESD Simulator w/Camera
A 30 kV ESD simulator for contact and air discharge immunity testing. Its integrated 1.5-megapixel camera displays the test point on a 3.5-inch color touchscreen and saves photographs before and after an impulse.
Includes a 150 pF / 330 ohm RC network, two rechargeable batteries and USB-C charging. The 30 kV model provides the highest listed family voltage; lower-voltage models can be upgraded with a purchased unlock code.
TS-CS114-CS115-CS116 TurnKey Test System for MIL-STD-461 CS114, CS115, CS116
Test System for MIL-STD-641 CS114, CS115, CS116
- Automatic calibration for the whole test frequency range
- Application of all test frequencies automatically. The level can be selected or automatic.
- NO need to manually configure the measurement equipment
- NO need to manually integrate the transfer function of probes and attenuators
- Generation of test reports: NO need to record all values read from the measurement equipment
- Generation of calibration reports: NO need to record all calibration setting parameters
- Rack together and add CS101, CS109, and RS101 (sections 18, 19, and 20 of the RTCA DO-160G are also available.)
PG-CS106 - CS106Test Generator, 500V
Highlights of the PG-CS106 Pulse Generator
- MIL-STD 461F CS106 Compliant: Ensures reliable military-standard testing.
- Flexible Configurations: Available as standalone (PG-CS106) or modular (M-CS106) units.
- High Performance: Delivers up to 500 V peak voltage and 8–100 A peak current.
- Precise Pulse Control: Supports 1–15 Hz repetition rates with swift rise and fall times.
- User-Friendly: Easy computer control via RS232 and USB interfaces.
- Compact & Portable: Lightweight design for both standalone (13 kg) and modular (1.2 kg) setups.
Enhance your naval and industrial testing with the PG-CS106 Pulse Generator—precision, compliance, and versatility in one powerful solution.
PG1275E - MIL-STD-1275E Surge/Spike Test Generator
Benefits of the PG1275E Pulse Generator
- MIL-STD-1275E Compliant: Dedicated design for conducted susceptibility testing on 28VDC circuits.
- Spike & Surge Testing: Handles spikes up to 260V / 2J and surges up to 200V / 470J.
- High Current Capability: 16A continuous or up to 400A with the optional DM400 decoupling diode module.
- Adjustable Waveforms: Configurable rise times, pulse durations, and voltages for precise test conditions.
- User-Friendly Control: Remote interface via RS232 or USB, with optional control software for automated testing.
Enhance your EMC testing with the PG1275E Pulse Generator—precision, compliance, and versatility combined.
IP-DR250 & CJ-DR250 BCI Bulk Current Injection probe 4kHz - 400MHz, 500 Watts
Highlights of the IP-DR250, One Probe to Unite All EMC Testing
- Frequency Range: 10 kHz to 400 MHz (extended: 4 kHz to 400 MHz with optional adapter)
- Power Handling: Up to 500 W CW (150 W – 60 min, 300 W – 30 min, 500 W – 15 min)
- Window Diameter: 43.8 mm
- Construction: Durable, shielded design with precision-machined housing
- Input Connector: Type N (Female)
