The TBCG1 is a radiating comb generator with an internal antenna and a base frequency of 100MHz. It radiates a comb spectrum characterized up to 6GHz. The comb generator is built and characterized to serve as a rough reference for testing radiated noise measurement set ups in anechoic chambers, TEM/GTEM cells, shielded chambers, etc.

The TBCG2 is a passive, step recovery diode based comb generator/frequency multiplier. It is optimized for moderate drive power and spectrum flatness in the frequency range 1 MHz to 2.5GHz. The recommended drive power is +10 dBm to +20 dBm The frequency range for the drive signal is 1 MHz to 350MHz

The TBAS3 RF 10W attenuator set consists of a 3dB, 6dB, 10dB and 20dB attenuator in a beech wood box.

The TBAS1 RF 2W attenuator set

The TBAS2 RF SMA attenuator/termination set consists of a 3dB, 6dB, 10dB, 15dB, 20dB and 30dB SMA attenuators in a beechwood box. Furthermore, it contains two pieces SMA 50 Ohm terminations.

CDN ABCL-35 Decoupling Clamp for immunity according to IEC / EN 61000-4-6 Ed. 4.0 100 kHz – 1000 MHz Features: For additional decoupling at immunity testing according to IEC / EN 61000-4-6 Suitable for cables up to 20mm diameter

• PLC Power Line Communications, ISN Impedance Stabilization Network
• 150 kHz - 30 MHz
• Max current 1.4A,
• Impedance of each path: 150 Ω

ESD Simulator Stand

• Easily and safely put the ONYX 16 or 30 ESD simulator in an upright position
• 2 holders for Air Discharge & Contact Discharge Tips when not in use
• Firmly holds the base and will not allow the simulator to tip.
• Easy grab-and-go

OM1 Duplex FSMA FSMA Indoor Duplex Fiber Patch Cable, Corning 62.5/125 Multimode fiber jumpers.  Each end pre-terminated with 2 stainless steel FSMA connectors.  OM1 duplex jumpers have 62.5um Corning optical core and 125um cladding for high speed, low loss, data transmission.  OFNR rated, orange colored, 3.0mm diameter, PVC jacket with zip-cord.

" An RF Probe Kit on Steroids"

• Fully integrated with Y.I.C. Technologies EMViewer software and EMProbe
• Normalization and correction when using the EMViewer software
• Flat response within the range of operation
• Slim Design and Protective Coating
• 18GHz Measured Cable included
• Lectures & Explanation Document
• Designed By Prof. Arturo Mediano, University of Zaragoza, Spain
