The TBMA6-P is a passive Loop Antenna for affordable EMC pre-compliance testing.  It has a frequency range of 9 kHz – 30 MHz, according to CISPR 16.

The TBMA2 is a biconical measurement antenna for EMC radiated emission testing and generating defined field strength. With its affordable price, it is an excellent choice for any lab carrying out in-house pre-compliance testing.

It is characterized from 30 MHz to 300 MHz and has a directional pattern similar to a dipole antenna.

The TBMA1 is a small, lightweight, wideband biconical measurement antenna. With its moderate price, it is ideal for radiated noise EMC pre-compliance testing and for generating defined field strength.

It is characterized from 30 MHz to 1 GHz and has a directional pattern similar to a dipole.

The TBMA3 is an affordable logarithmic periodic measurement antenna, targeting radiated noise EMC pre-compliance testing.

The TBMA3 is characterized from 250 MHz to 1.3 GHz and has VSWR and antenna factor values typical for log-periodic measurement antennas.

The TBMA4 is characterized from 1 GHz to 8 GHz and has a directional pattern typical for double ridged horn antennas.

The TBMA4 is a small double ridged horn antenna, with its radiating element made from edge-plated PCB substrate.

The TBTP1 tripod is a lightweight, compact tripod made out of carbon fiber and is suitable for all EMC antennas up to 6kg.

The TBL5016-1 50µH LISN is a device required to setup conducted noise measurements of DC or AC-powered electronic equipment. It is designed according to CISPR 16-1-2 and MIL-STD-461F standard and characterized in the frequency range of 9kHz to 100 MHz.

The TBL5016-3 is a Line Impedance Stabilization Network for the measurement of line-conducted interference within the range of 9 kHz to 30MHz, according to the CISPR 16-1-2 standard. The device is designed for testing 3-phase and single-phase, AC-powered equipment with supply voltages up to a maximum 450V/260V and 16A.

The TBL5032-3 is a Line Impedance Stabilization Network for the measurement of line-conducted interference within the range of 9 kHz to 30MHz, according to the CISPR 16-1-2 standard. The device is designed for testing 3-phase and single phase, AC-powered equipment with supply voltages up to maximum 450V/260V and 32A.

The TBL50100-1 50µH is a single channel 50 ohm // 50 µH LISN for the frequency range 150 kHz – 30 MHz according to CISPR 16-1-2.  In addition to conducted noise measurements on AC or DC supplied equipment, the LISN can be used to establish a defined impedance for a variety of other standardized tests.
