Convert from
dBV with Z = Ω
dBμV
=\(dBV + 120\)
dBmV
=\(dBV + 60 \)
dBμA
=\(dBV-20 \cdot log_{10}(Z) +
120\)
dBmA
=\( dBV-20 \cdot log_{10}(Z)+60 \)
dBA
=\( dBV -20 \cdot log_{10}(Z) \)
dBpW
=\( dBV -10 \cdot
log_{10}(Z)+120\)
dBm
=\( dBV-10 \cdot log_{10}(Z)+30 \)
dBW
=\( dBV-10 \cdot log_{10}(Z) \)
μV
=\( 10^{(dBV+120)/20} \)
mV
=\( 10^{(dBV+60)/20} \)
V
=\( 10^{dBV/20}\)
μA
=\( 10^{(dBV-20 \cdot
log_{10}(Z)+120)/20} \)
mA
=\( 10^{(dBV-20 \cdot
log_{10}(Z)+60)/20} \)
A
=\( 10^{(dBV -20 \cdot
log_{10}(Z))/20} \)
pW
=\( \frac{(10^{(dBV
/20)})^2}{Z}\cdot 10^{12} \)
mW
=\(
\frac{(10^{(dBV/20)})^2}{Z}\cdot 10^{3} \)
W
=\( \frac{(10^{(dBV/20)})^2}{Z} \)
