Find Field
Antenna Gain at the desired frequency
dBi
Test Distance
m
Amplifier Power
watts
System Losses (cable, connector, …)
dB
V/m
=\(
\frac{\sqrt{30\cdot Watts\cdot
10^[{\frac{Gain_{dBi}-Loss_{dB}}{10}}]}}{Meters}
\) CW Signal
%
=AM
Modulation Depth (per IEC 61000-4-3)
V/m
=
CWV/m / (1+AM%*0.01)
Find Required Power
Antenna Gain at the desired frequency
dBi
Test Distance
m
Desired Field level
V/m
System Losses (cable, connector, …)
dB
Watts
=\(
\frac{(V/m\cdot meters)^{2}}{30\cdot
10^{[\frac{Gain_{dBi}-Loss_{dB}}{10}]}} \)
CW Signal
%
=AM
Modulation Depth (per IEC 61000-4-3)
Watts
=
CWwatts *
(1+AM%*0.01)2
Find Antenna Gain Needed
Amplifier power
Watts
Test Distance
m
Desired Field level
V/m
System Losses (cable, connector, …)
dB
GaindBi
=\(
[10\cdot LOG{\frac{(V/m\cdot
meters)^{2}}{30\cdot Watts}}]+ Loss_{dB} \)
CW Signal
%
=AM
Modulation Depth (per IEC 61000-4-3)
GaindBi
=
CWGain+
20*LOG(1+AM%*0.01)
