POG-CS116 Damped Sinusoid Generator

Overview

The POG-CS116 Damped Sinusoid Generator by Absolute EMC is a state-of-the-art transient generator engineered to meet the rigorous requirements of MIL-STD 461 CS116 standards. Designed to verify the resilience of Equipment Under Test (EUT) against sinusoidal excitations on interconnecting cables, this generator is essential for ensuring the reliability and performance of naval and industrial electronic systems.

Key Features

MIL-STD Compliance: Fully compliant with MIL-STD 461 D/E/F/G CS116, ensuring adherence to military-grade testing standards.
Flexible Test Frequencies: Available in three configurations with varying numbers of discrete frequencies:
- POG-CS116-6: 6 test frequencies
- POG-CS116-9: 9 test frequencies
- POG-CS116-17: 17 test frequencies
- Enhanced frequency options (up to 17) allow for better excitation of EUT resonances.
Comprehensive Accessories: Can be ordered with essential accessories including an injection probe, attenuator, oscilloscope, and control software for a complete testing setup.
Efficient Testing Process: Single signal output eliminates the need for connection changes during testing, reducing test duration and enabling automated calibration and test sequences.
High Performance:
- Output Waveform: Damped oscillatory wave for accurate sinusoidal excitation.
- Output Current: Up to 10 A on 50 ohm.
- Output Impedance: Less than 100 ohm for optimal signal delivery.
User-Friendly Control: Fully controllable via computer through RS232 and USB interfaces, allowing seamless integration with your existing testing infrastructure.
Durable and Portable:
- Complete Unit: Weighs 34.5 kg with dimensions 630 x 530 x 485 mm.
- 19-inch Rack Module: Weighs 17.0 kg with dimensions 630 x 485 x 405 mm (9HU), ideal for space-constrained environments.
Wide Power Compatibility: Operates on 90-250 Vac, 50-60 Hz, with a power rating of 35 W / 75 VA, suitable for various power environments.
Robust Construction: Built to withstand demanding testing conditions with a storage temperature range of 5-50°C and an operating temperature range of 20-45°C.
Automation Software: Dedicated software application automatically calibrates the setup, sets perturbation levels, collects data, and generates comprehensive calibration and test reports.

Specifications

Parameter	POG-CS116-6	POG-CS116-9	POG-CS116-17
Standards	MIL-STD 461D/E/F/G, CS116	MIL-STD 461D/E/F/G, CS116	MIL-STD 461D/E/F/G, CS116
Output Waveform	Damped oscillatory wave	Damped oscillatory wave	Damped oscillatory wave
Test Frequencies	10, 100 kHz; 1, 10, 30, 100 MHz	10, 30, 100, 300 kHz 1, 3, 10, 30, 100 MHz	10, 18, 30, 56, 100, 180, 300, 560 kHz 1, 1.8, 3, 5.6, 10, 18, 30, 56, 100 MHz
Output Current	Up to 10 A on 50 ohm	Up to 10 A on 50 ohm	Up to 10 A on 50 ohm
Output Impedance	≤ 100 Ω	≤ 100 Ω	≤ 100 Ω
Damping Factor	15 ± 5	15 ± 5	15 ± 5
Repetition Rates	Single, 0.5 Hz, 1 Hz	Single, 0.5 Hz, 1 Hz	Single, 0.5 Hz, 1 Hz
Output Impedance / Connector	N 50 ohm	N 50 ohm	N 50 ohm
Storage Temperature	5 - 50°C	5 - 50°C	5 - 50°C
Operating Temperature	20 - 45°C	20 - 45°C	20 - 45°C
Control Interfaces	RS232 and USB	RS232 and USB	RS232 and USB
Power Supply	90 - 264 Vac / 47 - 63 Hz / 150 VA	90 - 264 Vac / 47 - 63 Hz / 150 VA	90 - 264 Vac / 47 - 63 Hz / 150 VA
Weight	34.5 kg (complete unit)	17.0 kg (19-inch rack module)	17.0 kg (19-inch rack module)
Dimensions (L x W x H)	630 x 530 x 485 mm	630 x 530 x 485 mm	630 x 530 x 485 mm

Applications

Naval Equipment Testing: Ensure the robustness of submarine and surface ship electronic systems against sinusoidal transient disturbances.
Quality Assurance: Validate the durability and reliability of AC and DC power leads in harsh and demanding environments.
Electromagnetic Compatibility (EMC) Testing: Assess and enhance the electromagnetic resilience of critical naval components and systems.
Research & Development: Facilitate the development of robust electronic systems capable of withstanding high-intensity sinusoidal excitations.
Precompliance Testing: Prepare your naval and industrial equipment for formal compliance by simulating real-world transient sinusoidal conditions.

Ordering Information

Choose the configuration that best suits your testing needs:

Type	Description
POG-CS116-6	Pulse generator for MIL-STD 461D/E/F/G CS116, 6 test frequencies, 19" rack version (Housing -9U Shown)
POG-CS116-9	Pulse generator for MIL-STD 461D/E/F/G CS116, 9 test frequencies, 19" rack version (Housing -9U Shown)
POG-CS116-17	Pulse generator for MIL-STD 461D/E/F/G CS116, 19 test frequencies, 19" rack version (Housing -9U Shown)
HOUSING-9U	Instrument case 9HU, 520mm, for stand alone use of the POG-CS116
IPDR250	Injection Probe: Compatible with CS114, CS115, or CS116 tests. Frequency range: 10 kHz - 400 MHz, internal diameter: 43.8 mm.
CJDR250	Calibration Jig: Designed for the IPDR250 injection probe.
SW-CS-DOW	Control software for MIL-STD-461 CS115 test setup
M-CS115	Module for MIL-STD 461 D/E/F/G CS115, to be installed in the POG-CS116-x generator
M-CS106	Module for MIL-STD-461F CS106, to be installed in the POG-CS116 modular generator
M-CS114	Module for MIL-Std 461 D/E/F/G CS114, to drive the signal of the external CS114 amplifier to the common output, to be installed in the POG-CS116-x generator
