NNBM 8124-800, 0.1 - 150 MHz, High Voltage, 800A, single path, Automotive LISN
NNBM 8124-400, 0.1 - 150 MHz, High Voltage, 400A, single path, Automotive LISN
NNBM 8124-200, 0.1 - 150 MHz, High Voltage, 200A, single path, Automotive LISN
NNHV 8123-800, 0.1 - 150 MHz, High Voltage, 800A, single path, Automotive LISN
NNHV 8123-400R, 0.1 - 150 MHz, High Voltage, 400A, single path, Automotive LISN
NNHV 8123-400, 0.1 - 150 MHz, High Voltage, 400A, single path, Automotive LISN
NNHV 8123-200, 0.1 - 150 MHz, High Voltage, 200A, single path, Automotive LISN
NNHV 8123, 0.1 - 150 MHz, High Voltage, 70A, single path, Automotive LISN
CMDM 8700 B Common mode / Differential mode switch
BAN 8508, BAN 8530, DC-Block 500 for testing to ISO 11452-7 or DC-10614
HVSE 8600, Shielded Enclosure for Automotive LISN
Products
NNBM 8124, 10 kHz - 150(400) MHz, High Voltage, 70A, single path, 5µH LISN
- Acc. to CISPR 25 Ed. 4, CISPR 16-1-2, DO 160, MIL-STD, or ISO 7637-2
- impedance (5µH + 1 Ohm) || 50 Ohm
- 70 A, 1000 V (DC)
- Switchable 50Ohm Load on measurement port
- 1 microfarad capacitor to ground on AE side
- BNC-jack (Type N option)
NNBM 8124-800, 0.1 - 150 MHz, High Voltage, 800A, single path, Automotive LISN
- Acc. to CISPR 25 Ed. 4, CISPR 16-1-2, or ISO 7637-2
- impedance (5µH + 1 Ohm) || 50 Ohm
- 800 A, 1000 V (DC)
- Switchable 50Ohm Load on measurement port
- 1 microfarad capacitor to ground on AE side
- BNC-jack (Type N option)
NNBM 8124-400, 0.1 - 150 MHz, High Voltage, 400A, single path, Automotive LISN
- Acc. to CISPR 25 Ed. 4, CISPR 16-1-2, or ISO 7637-2
- impedance (5µH + 1 Ohm) || 50 Ohm
- 250 A, 1000 V (DC)
- Switchable 50Ohm Load on measurement port
- 1 microfarad capacitor to ground on AE side
- BNC-jack (Type N option)
NNBM 8124-200, 0.1 - 150 MHz, High Voltage, 200A, single path, Automotive LISN
- Acc. to CISPR 25 Ed. 4, CISPR 16-1-2, or ISO 7637-2
- impedance (5µH + 1 Ohm) || 50 Ohm
- 200 A, 1000 V (DC)
- Switchable 50Ohm Load on measurement port
- 1 microfarad capacitor to ground on AE side
- BNC-jack (Type N option)
NNHV 8123-800, 0.1 - 150 MHz, High Voltage, 800A, single path, Automotive LISN
- Acc. to CISPR 25 Ed. 4 or BMW GS 95025-1
- impedance (5µH) || 50 Ohm
- 800 A, 1000 V (DC)
- Backside with built-in 0.1 microfarad capacitor to ground
- N-jack
NNHV 8123-400R, 0.1 - 150 MHz, High Voltage, 400A, single path, Automotive LISN
- Acc. to CISPR 16-1-2, CISPR 25 Ed. 4 or BMW GS 95025-1
- impedance (5µH) +1 Ohm || 50 Ohm
- 400 A, 1000 V (DC)
- Backside with built-in 0.1 microfarad capacitor to ground
- Switchable 1 microfarad on the backside Acc: ECE R10.06, CISPR 12 and PSA
- N-jack
NNHV 8123-400, 0.1 - 150 MHz, High Voltage, 400A, single path, Automotive LISN
- Acc. to CISPR 25 Ed. 4 or BMW GS 95025-1
- impedance (5µH) || 50 Ohm
- 400 A, 1000 V (DC)
- Backside with built-in 0.1 microfarad capacitor to ground
- N-jack
NNHV 8123-200, 0.1 - 150 MHz, High Voltage, 200A, single path, Automotive LISN
- Acc. to CISPR 25 Ed. 4 or BMW GS 95025-1
- impedance (5µH) || 50 Ohm
- 200 A, 1000 V (DC)
- Backside with built-in 0.1 microfarad capacitor to ground
- N-jack
NNHV 8123, 0.1 - 150 MHz, High Voltage, 70A, single path, Automotive LISN
- Acc. to CISPR 25 Ed. 4 or BMW GS 95025-1
- impedance (5µH) || 50 Ohm
- 70 A, 1000 V (DC)
- Backside with built-in 0.1 microfarad capacitor to ground
- N-jack
CMDM 8700 B Common mode / Differential mode switch
The measurement mode switch CMDM 8700 B expands the measurement possibilities of two V-LISN to T- and Delta-LISNs for the profound analysis of interference emissions.
BAN 8508, BAN 8530, DC-Block 500 for testing to ISO 11452-7 or DC-10614
- BAN broadband artificial network
- acc. ISO 11452-7 or DC-10614
- BAN 8508, 2 A - 8 A
- BAN 8530, 8 A - 30 A
- DC-Block 500, DC-blocking capacitor
HVSE 8600, Shielded Enclosure for Automotive LISN
- Shield Box for LISN
- Measurements of electric- or hybrid vehicles
- Aluminum
- Shielding Effectiveness: typ. > 100 dB
- CISPR 25 Ed. 4, BMW GS 95025-1
