Products
MAG 1000, 120A/m CW, 1100Am Short Duration, Power Frequency Magnetic Field
MAG 1000
- 1-120A/m Contiunus testing
- 100-1100A/m Short Duration 1-3sec
- Test either 50Hz & 60Hz Selectable
- 1m square Loop
CDN BCI-P1 Bulk Current Injection Probe 1 MHz – 400 MHz
BCI-P1 Bulk Current Injection Probe 10 kHz – 400 MHz - Meets specifications of ISO 11452-4:2005 and IEC 61000-4-6 - Frequency range from 1 MHz up to 400 MHz - Designed for automotive BCI testing - Low insertion loss (1MHz - 400MHz) to test bellow 1MHz (IEC/DO/MIL) see CDN BCI-P1_MT-1
CDN BCI-P1_MT-1 Bulk Current Injection Probe 4 kHz – 400 MHz
CDN BCI-P1_MT-1 Bulk Current Injection Probe 4 kHz – 400 MHz - Meets specifications of ISO 11452-4:2005, MIL-STD-461, DO-160 and IEC 61000-4-6 - Frequency range from 4 kHz up to 400 MHz - Designed for BCI testing
CDG CMP-45 Current Monitoring Probe, Foldable, with Calibration Set
CDG CMP-45 Current monitoring probe • Cable diameters up to 45 mm • Frequency range 10 kHz to 400 MHz • Foldable, easy positioning on the conductor / cable • For BCI testing acc. to ISO 11452-4 and others • Insertion impedance < 2,5 ?
CDG CMP-46 Current Monitoring Probe, with Calibration Set
CDG CMP-46 Current monitoring probe • Cable diameters up to 45 mm • Frequency range 10 kHz to 400 MHz • For BCI testing acc. to ISO 11452-4 and others • Insertion impedance < 2,5 ?
