ECSS LISN 2-75A, 10 Hz - 150 MHz, 75A, DC Lines, LISN

  • European Cooperation for Space Standardisation -LISN Line Impedance Stabilization Network
  • 10 Hz - 150 MHz
  • Max current 75A, (100A 15min)
  • Impedance of each path: 2 μH || 50 Ω

MARKETS:

TEST STANDARDS:

Data Sheet

SPECIFICATIONS



ECSS LISN 2-75A, 10 Hz - 150 MHz, 75A, DC Lines, LISN


The ECCSS LISN 2-75A was developed following the „European Cooperation for Space Standardisation“. The ECSS LISN 2-75A is used for DC mains lines. The redwing terminal must be connected to the positive voltage, the black terminal to the negative.

The impedance characteristic of each path is basically realized by an inductor in parallel with the 50 Ohm resistor: 2 μH || 50 Ω. The device under test has to be connected to the terminals at the front panel. The supply voltage has to be connected at the back panel. The device under test may drain a continuous current of 75 A and for a short period of time, it may even drain more than 100 A.





Specification
Frequency Range: 10 Hz - 150 MHz
Max. cont. Current: 75 A
Max. Current (limited time, 3 min): 100 A
Max. Voltage (DC): 200 V
Impedance  (2 µH ) || 50 Ω
DC-Resistance mains-EuT: 100 mΩ

EUT Connector: screw terminals M7x0.75
unscrewable with 4 mm jacks
Dimensions (W x H x D): 440 x 162 x 196 mm
Weight: 9.5 kg
Standard: ECSS-E-ST-20-07 Rev1
